If you’ve got two JBL EON 715 speakers and want to unlock true stereo sound or double your coverage, pairing them is the way to go. But if you’ve never done it before, the setup can feel a little intimidating especially if you’re in the middle of a gig and just need it to work. No worries, though. I’ve been running live sound for years, and I’ve paired these speakers more times than I can count. In this guide, I’ll walk you through the exact steps on how to pair 2 Jbl eon 715 speakers together, no guesswork, no fluff, just clear instructions that actually work.
What You Need to Connect Two JBL EON 715 Speakers
To connect Two Jbl Eon 715 Speakers Together for powerful stereo sound or extended coverage, you’ll need these essential items:
Required Equipment
- Two JBL EON 715 powered speakers
- XLR cables (recommended) or 1/4″ TRS cables
- Audio source (mixer, DJ controller, or audio interface)
Recommended Accessories
- Speaker stands for optimal placement
- Surge protector for equipment safety
Important Notes:
- XLR cables provide the cleanest signal with minimal interference
- Speaker stands help direct sound toward your audience
- Always power off the equipment when making connections
How To Pair 2 Jbl Eon 715 Speakers Together – Step-by-Step Guide
To pair two JBL EON 715 speakers together, connect them using XLR cables from your mixer’s main output to the first speaker’s input, then daisy-chain to the second speaker. This creates a professional stereo or mono sound system perfect for live performances and events.
Step-by-Step Connection Process:
- Optimal Speaker Placement
- Position speakers 6-10 feet apart
- Elevate to ear level (4-5 feet) using quality stands
- Angle 15-30 degrees inward toward audience center
- First Speaker Connection
- Use balanced XLR cable from mixer MAIN OUT
- Connect to INPUT 1 on first JBL EON 715
- Power on and set volume to neutral (12 o’clock)
- Second Speaker Setup
- Connect XLR from first speaker’s OUTPUT 1
- Run to second speaker’s INPUT 1
- Power on and match volume to first speaker
Professional Configuration Tips:
- Cable Selection: Always use shielded XLR cables for clean audio
- EQ Settings: Start with FLAT position on both speakers
- System Check: Test at performance volume before event
- Power Management: Connect to surge-protected power source
Common Issues & Solutions:
- No Sound from Second Speaker: Verify OUTPUT 1 connection is secure
- Audio Hum/Buzz: Enable ground lift switch on speakers
- Distortion: Reduce input gain on speakers
- Channel Imbalance: Check all cables for damage
While the JBL EON 715 delivers powerful live sound, gamers needing precise audio positioning might prefer these dedicated Gaming Soundbars with low-latency modes.
How to Connect Two JBL EON 700 Speakers – The Professional’s Guide
To connect two JBL EON 700 speakers, use XLR cables to daisy-chain them: (1) Connect mixer to first speaker’s input, (2) Run XLR from first speaker’s output to second speaker’s input, (3) Power on both, (4) Set volumes to unity. This creates a perfect stereo or mono setup for live sound.
Step-by-Step Setup Guide
1. Speaker Placement for Optimal Sound
- Position speakers 8-12 feet apart
- Elevate to ear level (4-6 feet) using sturdy stands
- Angle 30° inward toward audience center
- Avoid placing near walls to prevent bass buildup
2. Required Equipment Checklist
- 2 JBL EON 700 series speakers (715/712/710/708)
- High-quality shielded XLR cables (2 needed)
- Audio source (mixer, controller, or interface)
- Surge protector power strip
3. Connection Process (Numbered Steps)
Step 1: First Speaker Connection
- Connect XLR from mixer MAIN OUT to:
- INPUT 1 on first JBL EON 700
- Power on first speaker
- Set volume to unity (12 o’clock position)
Step 2: Daisy-Chain Second Speaker
- Connect second XLR from:
- OUTPUT on first speaker to
- INPUT 1 on second speaker
- Power on second speaker
- Match volume to first speaker
Professional Configuration Tips
- Cable Quality: Use Mogami or equivalent XLR cables
- EQ Settings: Start flat, adjust via JBL Pro Connect app
- System Check: Test at 75% performance volume
- Safety First: Power off before connecting/disconnecting
While the JBL EON 700 series excels for live sound, those needing home theater audio might prefer our tested Dolby Atmos soundbars for cinematic experiences.
Troubleshooting Common Issues
Problem: No sound from second speaker
Solution: Check OUTPUT connection and cable continuity
Problem: Hum/buzz in audio
Solution: Enable ground lift on both speakers
Problem: Distortion at high volumes
Solution: Reduce mixer output, increase speaker volume
FAQS:
Q: Can you connect JBL EON 700 speakers without a mixer?
A: Yes, you can connect two JBL EON 700 speakers directly to an audio source using XLR cables. Simply run a cable from your device’s output to the first speaker’s input, then daisy-chain to the second speaker. For best results, keep cable lengths under 20 feet when skipping a mixer.
Q: What’s the best way to connect two JBL EON 715 speakers for stereo sound?
A: For perfect stereo sound:
- Place speakers 8-12 feet apart
- Connect left channel to first speaker’s input
- Connect right channel to second speaker’s input
- Pan hard left/right at your mixer
- Match volume levels on both speakers
Q: How do I know if my JBL EON 700 speakers are properly connected?
A: Check these three things:
• Both speakers power on (LED indicators lit)
• Audio plays through both when testing left/right channels
• No hum or distortion at performance volume
Q: Can I use 1/4″ cables instead of XLR for EON 700 speakers?
A: Yes, but XLR is preferred. 1/4″ cables work for short runs (under 15 feet), but may introduce noise. For professional setups or longer distances, always use balanced XLR connections.
Q: Why is one of my paired EON 700 speakers quieter than the other?
A: First check:
- Volume knobs on both speakers
- Cable connections at each input/output
- Mixer channel balance
- Cable quality (swap cables to test)
Q: What’s the maximum distance between two connected EON 700 speakers?
A: While you can space them up to 50 feet apart with quality XLR cables, we recommend 8-20 feet for:
• Better stereo imaging
• Easier volume matching
• Reduced cable interference
Q: How do I stop humming noise in my connected EON 700 system?
A: Three quick fixes:
- Enable the ground lift switch on both speakers
- Ensure all devices share the same power circuit
- Replace cheap cables with balanced XLR
Q: Can I add a subwoofer to two connected EON 700 speakers?
A: Absolutely. Connect your subwoofer’s output to the EON 700’s inputs, or use the speakers’ high-pass filter if available. This creates a full-range system perfect for music and live sound.
Pro Tip: Always do a sound check at performance volume before your event. Walk the room to verify both speakers sound clear and balanced at all listening positions.
Conclusion:
By following this guide, you now have everything you need to know on How To Pair 2 Jbl Eon 715 Speakers Together for professional-quality sound. Whether you’re setting up for a live gig, DJ performance, or event, these key takeaways will ensure success:
- Simple Setup – Just connect via XLR, daisy-chain, and power on
- Pro Sound Quality – Proper placement and cabling make all the difference
- Trouble-Free Operation – Our troubleshooting tips solve common issues quickly
Ready to Get Started? Grab your cables, position your speakers, and you’ll be ready to perform in minutes. For optimal results, remember to:
- Always use balanced XLR cables
- Perform a full sound check before your event
- Keep volumes matched between speakers
This isn’t just another generic tutorial – it’s the exact method audio professionals use to get the best performance from their JBL EON 700 systems. Now you’re equipped with that same expertise.
